Vibration Testing Machine, Vibration Controller Performs Sine, Random, Shock

Ask Lasest Price
Brand Name :	LABTONE
Model Number :	EV450
Certification :	CE / ISO
Price :	Negotiable
Payment Terms :	T/T, L/C
Supply Ability :	15 Sets / Month
Delivery Time :	45 Working Days

Add to Cart

Product Details
Company Profile

Vibration Testing Machine, Vibration Controller Performs Sine, Random, Shock

Vibration Testing Machine, Vibration Controller Performs Sine, Random, Shock

Introduction:

EV series of electromagnetic vibration testing system simulate the vibration environment under the laboratory condition, and test the impact strength as well as reliability of various vibration test applications. In the laboratory, with the aid of vibration testing system, simulations of reproduction of sinusoidal, random, resonant search and dwell, classical shock and road models, etc. can be achieved. It is essential for product quality assurance, new product research and development.

Specifications:

Model	EV450
Vibration Generator	VG5000/100
Frequency(Hz)	1-2500
Max Exiting Force(kg.f)	5000
Max. Displacement (mmp-p)	101.6
Max. Acceleration(g)	82
Max. Velocity(cm/s)	250
Payload(kg)	1000
Armature Mass(kg)	60
Armature Diameter(mm)	φ445
Cooling Method	Forced Air Cooling
Vibration Generator Weight(kg)	4500
Vibration Generator Dimension LWH(MM)	110013001520
Power Amplifier	Amp70k
Cooling Method	Forced Air Cooling
Power Amplifier Weight(kg)	900
Power Amplifier Dimension LWH(MM)	8005501920
Utility Requirements	3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW)	75

Key Applications:

Automotive parts and systems - qualification testing
Electronic assembly, computer equipment testing
Avionics and military hardware testing
Satellite component testing
Product and package testing
General stress screenin

Features:

Rugged suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability.
Load center airbag with high static stiffness and low dynamic stiffness, strong carrying capacity, perfect performance on amplitude variation.
High efficiency D class power switching, 3-sigma peak current, low power consumption and minimum harmonic distortion.
Quick self-diagnosis with safety interlock, high safety reliability.
Airbag shock isolation device for vibration platform without the need of additional. foundation, perfect reproduction of vibrational wave and reduction in vibration transmittance.
Horizontal and vertical expansion platforms for different applications.
Simple controller operation.

Customer Services

Presales:

Technical consultation: test method, laboratory planning and suggestion.
Equipment selection: selection scheme, FAQ.
Product testing scheme.

In-Sales:

Customer communication and progress report.
Guidance for pre-installation preparation, equipment commissioning and test run.
Calibration (when Third Party’s verification is required).

After-Sales:

Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.

Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.

Technical support: special paid services are provided according to customer’s needs.

Packing:

Metering:
