High Acceleration Mechanical Shock Test Equipment For Mobile phone and Component

Ask Lasest Price
Brand Name :	LABTONE
Model Number :	G-HSKT5
Certification :	CE, ISO
Price :	Negotiable
Payment Terms :	T/T
Supply Ability :	15 Sets / Month
Delivery Time :	45 working days

Add to Cart

Product Details
Company Profile

High Acceleration Mechanical Shock Test Equipment For Mobile phone and Component

Mechanical Shock Equipment High Acceleration Shock Tester For Mobile phone and Component

Product description

Products are inevitably affected by impact, bump, free fall, tumbling, etc. during production, transportation, loading and unloading as well as during the use of the products. All of these are transient excitation on the object, causing the object to produce mechanical characteristics of high speed, acceleration, strain rate, etc instantly.These kind of characteristics are completely different from that in static load, and may cause problems to the object in terms of structural strength and stability and sometimes the object may fail. Therefore, it is necessary to study the effect of impact and reproduce the shock environment, to assess the structural strength and performance of the object under shock environment.

Shock testing systems Specifications

Model	HSKT10	HSKT10D	HSKT15	HSKT30	HSKT35
Table Size(mm)	200 x 250	300 x 300	250 x 250	250 x 250	250 x 250
Max. Payload (kg)	10	25	10	10	10
Shock Pulse	Half Sine Wave
Acceleration Range(G)	20~2000 (bare table)	20~10000 (bare table)	20~15000 (bare table)	20~30000 (bare table)	20~35000 (bare table)
Pulse Duration(ms)	0.2~18		0.1~11

Model		SKT30	SKT50	SKT100	SKT200	SKT300	SKT600	SKT1000
Table size (cm)		40*40	50*60	70*80	100*100	120*120	150*150	200*200
Maximum Specimen Weight(Kg)		30	50	100	200	300	600	1000
Max acceleration(G)	half sine	600	600	600	500	500	300	300
	saw-tooth waveform	100	100	100	100	100	100	100
	square	150	150	150	150	100	100	100
Pulse Duration (ms)	half sine	40—0.2	40~1	40~1	30~2	20~3	20~3	20~3
	saw-tooth waveform	18~6	18~6	18~6	18~6	18~6	18~6	18~6
	square		30~6	30~6	30~6	30~6	30~6	30~6
Machine Dimension(cm)		120110245	130140260	130120260	150130260	200160300	230180310	250220310
Controller cabinet Dimension(cm)		W55D50H80
Machine Weight(Kg)		1900	2300	3200	4200	8500	15500	19500
Utility		3-phase AC380V 50/60Hz 0.5~0.8MPa
Requirements		3-phase AC380V 50/60Hz 0.5~0.8MPa
Conforming standards		GB/T2423-2008 GJB1217 GJB360.23 GJB150 GJB548 MIL-STD-202F IEC-68-2-27 MIL-STD-883E MIL-STD-810F ISTA UL

Company Profile:

Labtone Test Equipment Co., Ltd. is a +15 year China manufacture of reliable, cost-effective equipments. Our superior products mainly include: Vibration Test Systems, Shock Test Systems, Bump Test Systems, Drop Tester, Packaging Transportation Simulators, and Combined Environmental Test Chambers.

Labtone started business in 2002 in a plant located in Shenzhen and moved to our new, expanded 6,000 square meter facility in Dongguan, Guangdong in 2015. Today, our products are found around the world in electronics, automotive, aerospace, telecommunication, optoelectronics instrument and industrial machinery applications. Our experience and commitment to new product development has resulted in products that are easy to use, accurate and designed for decades of service.

Labtone products carry a one-year(12months) warranty. We provide comprehensive factory services and supports, technical literatures, manuals and guides as well as having qualified staffs and experts to solve your problems.
