Simple Operation Shaker Test Equipment , Vibration Shaker Table Systems

Ask Lasest Price
Brand Name :	LABTONE
Model Number :	EV350
Certification :	CE / ISO
Price :	Negotiable
Payment Terms :	T/T, L/C
Supply Ability :	15 Sets / Month
Delivery Time :	45 Working Days

Add to Cart

Product Details
Company Profile

Simple Operation Shaker Test Equipment , Vibration Shaker Table Systems

Vibration Testing Shaker Table For Computers Laptops Vibtrtion Test With IEC Standard

Applicable Standards: MIL-STD, DIN, ISO, ASTM, IEC, ISTA, GB, GJB, JIS, BS etc.

Applicable Industries: Automotive, Electronics, Aerospace, Vessel, Telecommunication, Optoelectronics, Instrument etc.

Specifications: EV340-EV440

Model	EV340	EV350	EV420	EV430	EV440
Vibration Generator	VG4000/76	VG5000/76	VG2000/100	VG3000/100	VG4000/100
Frequency(Hz)	2-2500	2-2500	2-3000	2-2500	2-2500
Max Exiting Force(kg.f)	4000	5000	2000	3200	4000
Max. Displacement (mmp-p)	76	76	100	100	100
Max. Acceleration(g)	80	100	90	71	66
Max. Velocity(cm/s)	200	200	200	250	250
Payload(kg)	1000	1000	500	500	800
Armature Mass(kg)	50	50	23	45	60
Armature Diameter(mm)	φ440	φ440	φ320	φ400	φ445
Cooling Method	Forced Air Cooling
Shaker Weight(kg)	3500	3800	2000	3200	4200
Shaker Dimension LWH(MM)	110013001520	110013001520	85010001100	110013001440	110013001520
Power Amplifier	Amp55k	Amp70k	Amp35k	Amp40k	Amp60k
Power Amplifier Weight(kg)	800	900	550	600	800
Power Amplifier Dimension LWH(MM)	8005501920	8005501920	8005501920	8005501920	8005501920
Utility Requirements	3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW)	80	90	45	64	85

Features:

Strength of the suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability.
Perfect performance on amplitude variation.
High efficient on D Class power conversion, 3 - Sigma peak current, provide the optimization of power consumption and minimum harmonic distortion.
Rapid self-test diagnostics and chain safeguard, high high safety and reliability
Air gasbag isolation damping device realize the the vibration table with no need for special foundation. Perfect reappearance vibration waveform and the reduction of vibration transmission
Different application on the vertical and horizontal tables.
Simple operation for the controller.

Our Services

Pre-Sales Service

1)Technical consultation: test method, laboratory planning and suggestion.

2)Equipment selection: selection scheme, FAQ.

3)Product testing scheme.

4)Customer communication and progress report.

After-Sales Service

1)Technical training: operation of equipment, daily maintenance, common fault diagnosis and troubleshooting.

2)Scheduled on-site service: Detection of problem as soon as possible in order to eliminate equipment and anthropogenic hazards. This is to ensure long term and stable equipment operation as well as delivery of latest technical information.

3)Technical support: special paid services are provided according to customer’s needs.
