Shock Testing : End Results
· Highly reliable and more robust product
· Identify and correct design deficiencies
· Facilitate world-wide shipment and delivery of a high-quality
product
· Better able to meet customer demands and warranty Claims
Reduce costs and create profit!!
| Model | HSKT10 | HSKT10M | G-HSKT15 | G-HSKT30 | G-HSKT35 |
| Table Size(mm) | 200 x 250 | 200 x 200 | 250 x 250 | 250 x 250 | 250 x 250 |
Max. Payload (kg) | 10 | 5 | 10 | 10 | 10 |
| Shock Pulse | Half Sine Wave |
| Acceleration Range(G) | 20~2000
| 20~3000g
| 20~15000
| 20~30000
| 20~35000 |
| Pulse Duration(ms) | 0.2~18 | 0.1~11
|
| Model | SKT30 | SKT50 | SKT100 | SKT200 | SKT300 | SKT600 | SKT1000 | |
| Table Size (cm) | 40 x 40 | 50 x 60 | 70 x 80 | 100 x 100 | 120 x 120 | 150 x 150 | 200 x 200 | |
| Max. Specimen Weight(kg) | 30 | 50 | 100 | 200 | 300 | 600 | 1000 | |
Max. Acceleration (G) | Half Sine | 600 | 600 | 600 | 500 | 500 | 300 | 300 | |
| Saw-tooth | 100 | 100 | 100 | 100 | 100 | 100 | 100 | |
| Square | | 150 | 150 | 150 | 100 | 100 | 100 | |
Pulse duration (ms) | Half Sine | 30—0.5 | 30～1 | 30～1 | 30～2 | 20～3 | 20～3 | 20～3 | |
| Saw-tooth | 18～6 | 18～6 | 18～6 | 18～6 | 18～6 | 16～6 | 18～6 | |
| Square | | 30～6 | 30～6 | 30～6 | 30～6 | 30～6 | 30～6 | |
| Controller cabinet dimension(cm) | W55*D50*H80 |
| Machine weight(Kg) | 1900 | 2300 | 3200 | 4200 | 8500 | 15500 | 21500 | |
| Power supply | 3(phase) AC380V 50/60Hz Compressed air 0.5～0.8MPa |
| Standards | GB/T2423-2008 GJB1217 GJB360.23 GJB150 GJB548 MIL-STD-202F
IEC-68-2-27 MIL-STD-883E MIL-STD-810F ISTA UL
|
Company Profile:
Labtone Test Equipment Co., Ltd. is a +15 year China manufacture of
reliable, cost-effective equipments. Our superior products mainly
include: Vibration Test Systems, Shock Test Systems, Bump Test
Systems, Drop Tester, Packaging Transportation Simulators, and
Combined Environmental Test Chambers.
Labtone started business in 2002 in a plant located in Shenzhen and
moved to our new, expanded 6,000 square meter facility in Dongguan,
Guangdong in 2015. Today, our products are found around the world
in electronics, automotive, aerospace, telecommunication,
optoelectronics instrument and industrial machinery applications.
Our experience and commitment to new product development has
resulted in products that are easy to use, accurate and designed
for decades of service.
Labtone products carry a one-year(12months) warranty. We provide
comprehensive factory services and supports, technical literatures,
manuals and guides as well as having qualified staffs and experts
to solve your problems.
We sincerely invite you to visit our factory.
