    35000g High Speed Shock Test Machine Table Size 300*300mm Meet Industry Test Spec

    Ask Lasest Price
    Brand Name : LABTONE
    Model Number : G-SKT30
    Certification : CE, ISO
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 15 Sets / Month
    Delivery Time : 60 working days
    • Product Details
    • Company Profile

    35000g High Speed Shock Test Machine Table Size 300*300mm Meet Industry Test Spec


    35000g High Speed Shock Test Machine Table Size 300*300mm Meet Industry Test Spec​


    Introduction to Equipment Performance


    a Working platform (Table)

    High strength imported aluminum alloy working platform.


    b lifting mechanism

    PLC control servo motor drive ball screw to raise working platform.


    c Lifting height control

    The height of lifting is measured by the photoelectric encoder module installed on the base.The photoelectric encoder measurement has high precision, strong anti-interference ability and high reliability, which ensures the repeatability of impact


    d Brake System

    Adopt the gas-liquid supercharged brake force friction lock to prevent the secondary backlash.


    e Buffer System

    Effectively reduce the impact on the ground. The self - cushioning system is designed with base, damper and air bag.


    f Waveform Generator

    Half sine waveform generator: Wool felt, polyurethane, ect.


    Technical Parameters:


    Main parameters of the shock tester
    Operating platform300 × 300 mm
    Max. load30 KG
    Peak acceleration200-100000m/s2 (20-10000G)
    Pulse duration1~11 ms (Half sine wave)
    Equipment dimensions1300×1220×3380 mm
    Equipment weight1950 kg
    Power & Air supply3phase 380V±10％ 50Hz,5KVA & 0.5—0.7MPa
    Dual Mass Shock Amplifier
    Table size150 x 150 mm
    Max. load3kg
    Peak acceleration35000G
    Pulse duration0.1—0.5ms
    Measuring system
    Input channels4 channels
    Sampling frequency1MHz
    Input modeSupport voltage, IEPE, input directly.
    Coupled modeAC, ICP
    ADC resolution16 bits
    Dynamic range80dB
    harmonic distortion<-70dB
    Signal to Noise Ratio>70dB
    Pulse durationNarrow -0.1ms
    Acceleration rangeUp to 100,000gn
    Frequency accuracy0.01%
    Voltage range-10Vpeak--+10Vpeak
    Supportive standardGB, GJB, MIL-STD, ISO, IEC, user defined
    Shock waveformHalf-sine
    Communication interfaceUSB2.0
    Operating systemWin7/10
    System accelerometer
    BrandDYTRAN (USA)
    Type 1Measuring and analyzing three axial acceleration sensors
    Model3133A5
    Output modeIEPE type
    Sensitivity0.25mv/g ± 25%
    Frequency range0.25---10KHz ±10%
    Acceleration range20000G (40000G MAX)
    Operating environment-55 to +160℃
    Type 2Shock acceleration sensors
    Model3200B2T
    Output modeIEPE type
    Sensitivity0.05 mV/g±25%
    Frequency range0.5 to 20K Hz frequency range (±10%)
    Acceleration range50000G
    Operating environment-51 to +121℃

    Warranty: within 12 months after customer receive the goods, lifelong time maintainance.

    After-sale service: feedback within 4-8 hours after get the call or email.

    Service: OEM, ODM


    Certificate: China official third-party calibration report / CE Certification



    Packaging:


    bubble bag + vacuum package + plywood case
