Battery Vibration Test System Comply With UN38.3 IEC62133 8G Acceleration

Ask Lasest Price
Brand Name :	LABTONE
Model Number :	EV206
Certification :	CE / ISO
Price :	Negotiable
Payment Terms :	T/T, L/C
Supply Ability :	15 Sets / Month
Delivery Time :	45 Working Days

Add to Cart

Product Details
Company Profile

Battery Vibration Test System Comply With UN38.3 IEC62133 8G Acceleration

Battery Vibration Test System Comply with UN38.3 IEC62133 8G Acceleration

Vibration Test Machine Applicable Battery Test Standards: IEC 62133, EN 50604, UN 38.3

Vibration Test Machine Applicable Industries: Automotive, Electronics, Aerospace, Vessel, Telecommunication, Photoelectronics, Instrument etc.

Vibration Test Machine Configuration and Specifications

Item	Configuration	Qty.
1.	Vibration Shaker
	Electromagnetic vibration generator VG600-50	1 set
	Cooling blower (including silencer) BL-600	1 set
	Automatic centering system of armature	1 set
	Head Expander VT640	1 pc
2.	Power Amplifier
	Digital switch power amplifier Amp6k	1 set
3.	Vibration controller (integrated to the controll cabinet)
	Master unit of digital vibration controller	1 set
	System acceleration sensor	1 pcs
	Control computer	1 set
	Control software installation disc	1 set
4.	Attached accessories
	Extension cable and duct hose	1 set
	Operation instructions, inspection report, certificate, maintenance manual, etc.	1 set
	Attached special tools	1 set
	Vibration press rod / holddown strip fixture	1 set

Model	EV206
Vibration Generator	VG300/50
Frequency(Hz)	2-3000
Max Exiting Force(kg.f)	600
Max. Displacement (mmp-p)	50
Max. Acceleration(g)	100
Max. Velocity(cm/s)	200
Payload(kg)	200
Armature Mass(kg)	6
Armature Diameter(mm)	φ200
Cooling Method	Air Cooling
Vibration Generator Weight(kg)	920
Vibration Generator Dimension LWH(MM)	800600710
Power Amplifier	Amp6k
Cooling Method	Forced Air Cooling
Power Amplifier Weight(kg)	320
Power Amplifier Dimension LWH(MM)	8005501250
Utility Requirements	3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW)	20

Vibration Test Machine simulates the vibration environment under the laboratory condition, and test the impact strength as well as reliability of various vibration test applications. In the laboratory, with the aid of vibration testing system, model simulation of reproduction of sinusoidal, random, resonant search and dwell, classical shock and road simulation, etc. can be achieved. It is essential for product quality assurance, new product research and development.

Features:

Rugged suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability
Load center airbag has high static stiffness and low dynamic stiffness, strong carrying capacity, perfect performance on amplitude variation
High efficiency D class power switching, 3-sigma peak current, provide finest power consumption and minimize harmonic distortion
Quick self-diagnosis with safety interlock, high safety reliability
Airbag shock isolation device for vibration platform without the need of additional foundation, perfect reproduction of vibrational wave and reduce vibration transmittance
Provide horizontal and vertical expansion platform for different application
Simple controller operation

Use Scenarios

Qualification testing of automotive parts and systems, including industry standards like ISO/TS 16949, Squeak and Rattle tests, and Road Load Data applications
Electronic assembly and computer equipment testing
Avionics and military hardware testing, such as Mechanical Environmental Tests AECTP 400, ISO 9000, MIL-STD and AS9000 standard tests
Telecommunication and satellite component testing
General stress screening, including ISO 5344, HALT, ALT and HASS
Product and package testing, such as ISTA and ASTM 4169 tests
Shock test applications, including Shock Response Spectrum (SRS)
Environmental testing with AGREE chambers, Combined Environmental Reliability Test (CERT) and others
